Motor Servo DC 24V

BLDC Servo Motor 40W with 1:25 Ratio and 3.8nm Output Torque for Fast Opening Swing Gates

Semua Kategori

Motor Servo Untuk Pelacak Surya

Motor Penggerak Truk Galik Listrik

Pengontrol Gerbang Putar

Hubungi kami

Ms. Chilli

Chillijy@jiayume.com

15218146199

15218146199

Hubungi sekarang

BLDC Servo Motor 40W with 1:25 Ratio and 3.8nm Output Torque for Fast Opening Swing Gates

Nama merek:	CSJY
Nomor Model:	MBS70F-40A-1825-V3
MOQ:	2 pcs
harga:	Negotiate
Rincian kemasan:	Karton
Ketentuan Pembayaran:	T/t

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Sertifikasi:

Dokumen:

Aplikasi:

Swing gate, speed gate, sliding gate

Fitur:

pembukaan cepat dan anti-pinch yang sensitif

Tegangan Dinilai:

DC24V

Kekuatan Dinilai:

Nilai arus:

Kecepatan Dinilai:

1800rpm

Perbandingan:

Torsi output:

3.8nm

Menyediakan kemampuan:

5000pcs/bulan

Menyoroti:

1:25 Ratio BLDC Servo Motor

3.8nm Output Torque 24V DC Servo Motor

Fast Opening Brushless DC Motor

Deskripsi Produk

BLDC Servo Motor 40W 1:25 for Swing Gate Turnstile

The BLDC Servo Motor 40W 1:25 is a high-performance, brushless DC motor system engineered for demanding automation and access control applications. This integrated servo solution combines a powerful 40-watt brushless motor with a precision 1:25 ratio planetary gearbox, delivering exceptional torque, smooth operation, and long-term reliability.

Application	swing gate, speed gate, sliding gate
Features	fast opening and sensitive anti-pinch
Rated voltage	DC24V
Rated power	40w
Rated current	3A
Poles	5
Rated speed	1800rpm
Ratio	1:25
Output speed	72rpm
Output torque	3.8nm

Features

High-Efficiency BLDC Motor: Brushless DC technology offers superior performance, higher torque, and a longer lifespan than brushed alternatives, with no carbon brushes to replace.
Robust Planetary Gearbox: The high-precision 1:25 reduction ratio gearbox provides high output torque, excellent durability, and low backlash for reliable and accurate movement.
Integrated Servo Control: Comes with a matching servo controller for precise speed and position control, enabling smooth starts and stops to reduce mechanical stress.
High Torque Density: Delivers exceptional torque (approx. 4-5 Nm) from a compact form factor, perfect for space-constrained installations.
Quiet and Smooth Operation: Ideal for residential and commercial environments where noise reduction is important.
Reliable & Maintenance-Free: Sealed construction and brushless design ensure consistent operation with minimal maintenance, even in harsh outdoor conditions.
Thermal Protection: Built-in safeguards protect the motor from overheating under heavy loads or continuous operation.

Applications

Swing gate
Speed gate
Tripod turnstile gate
Sliding gate
Flap gate
