Low Voltage 750W DC48V Servo Motor with Absolute Encoder

Nama merek:	CSJY
Nomor Model:	GEBS80F-750C-30T2E5Z-B1EL-ST-01
MOQ:	2 buah
harga:	Negotiate
Rincian kemasan:	karton
Ketentuan Pembayaran:	T/T

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Sertifikasi:

Dokumen:

Resolusi Encoder:

Encoder Absolut Multi-putaran 17-bit

Nilai daya:

750 watt

Nilai Tegangan:

48 VDC

Kecepatan terukur:

3000 rpm

Berat:

2.35kg

Protokol komunikasi:

RS485/BISAterbuka

Kelas Perlindungan:

Torsi Terukur:

2,4NM

Batang:

Dikunci, digiling, dengan segel

Suhu lingkungan:

-25°C sampai +55°C

Menyediakan kemampuan:

500 buah/bulan

Deskripsi Produk

Low Voltage 750W DC48V Servo Motor with Absolute Encoder

Product Description

Engineered for superior performance in modern automation, the Low Voltage 750W DC48V Servo Motor is the intelligent choice for applications where operational efficiency, precision, and system safety are paramount. This motor operates on a 48VDC system—a safer, more accessible, and increasingly standard industrial voltage that simplifies electrical infrastructure and reduces safety risks compared to higher voltage alternatives. Its defining feature is the integrated absolute encoder, which provides immediate, high-resolution positional feedback upon power-up.

Technical Specifications

Rated Power	750 Watts
Rated Voltage	48 VDC
Rated Speed	3000 RPM
Rated Torque	2.4nm
Feedback Device	Multi-turn Absolute Encoder
Communication Protocol	CANopen
Protection Class	IP65 (Standard)

Low Voltage 750W DC48V Servo Motor with Absolute Encoder 0

Key Features

Safe Low-Voltage Operation: 48VDC power simplifies compliance with electrical safety standards, reduces insulation requirements, and allows for easier integration in diverse environments.
Absolute Encoder for Immediate Start-Up: Enables true "power-on-and-go" functionality. The system knows its exact position at start-up, eliminating homing delays and enhancing operational safety.
High Power & Compact Design: Delivers 750W of continuous power in a space-efficient package, offering excellent torque density for applications with size and weight constraints.
Optimized Thermal Performance: Advanced cooling design and high-efficiency magnets ensure stable performance and long life, even during demanding duty cycles.
High Dynamic Response & Precision: Features low rotor inertia for rapid acceleration/deceleration and smooth motion, critical for high-accuracy path following and positioning.
Robust Industrial Construction: Built with high-grade materials, precision bearings, and protective sealing (e.g., IP65) to ensure reliable operation in dusty or demanding industrial settings.
Plug-and-Play Compatibility: Designed with standardized mechanical interfaces and connectors for straightforward integration with most common 48V servo drives.

Applications: Collaborative Robots (Cobots), Precision Automation Cells, Medical Device Assembly, Laboratory Automation, Semiconductor Handling, Advanced Packaging Machinery, and AGV Drive Wheels.

Low Voltage 750W DC48V Servo Motor with Absolute Encoder 1
