24V DC 8A Incremental Encoder Servo Driver for Speed Gate and Turnstile Applications

Nama merek:	CSJY
Nomor Model:	GEPS2408-AD
MOQ:	1
harga:	according to quantities
Rincian kemasan:	Karton
Ketentuan Pembayaran:	T/T

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Sertifikasi:

Tegangan Masukan:

24 VDC / 48VDC

Nilai/Arus Puncak:

8 /24 lengan

Masukan:

HALLU、HALLV、HALLW、EA、EB、EZ enkoder tambahan, pasokan listrik +5V Dukungan input diferensial; Dukunga

Komunikasi:

RJ45, termasuk RS232, RS485, Can

Perlindungan perangkat keras:

Sambungan terbalik input daya, sirkuit pendek fase, sirkuit pendek 5V, output rem sirkuit pendek per

Suhu penggunaan:

-20 ～ 55 ℃, tidak beku, beban rata -rata tidak boleh melebihi 80% dari beban pengenal;

Kelembaban penggunaan:

Di bawah 90% RH, tidak ada kondensasi

Aplikasi:

gerbang ayunan, gerbang kecepatan, gerbang geser atau gerbang flap

Menyediakan kemampuan:

5000+PC/bulan

Menyoroti:

24V DC servo driver

pedestrian turnstile servo driver

channel gate motor driver

Deskripsi Produk

Low Voltage Incremental Encoder DC Servo Driver Specially Designed for Turnstile Gates

24V DC 8A Incremental Encoder Servo Driver for Speed Gate and Turnstile Applications 0

24V DC 8A Incremental Encoder Servo Driver for Speed Gate and Turnstile Applications 1

24V DC 8A Incremental Encoder Servo Driver for Speed Gate and Turnstile Applications 2

24V DC 8A Incremental Encoder Servo Driver for Speed Gate and Turnstile Applications 3

24V DC 8A Incremental Encoder Servo Driver for Speed Gate and Turnstile Applications 4

Application Features:

① Integration of industry-leading channel movement control logic algorithm；

② The Open speed is fast up to 0.3 seconds；

③ Forced Prevented is responsive,locked in small angle；

④ Built-in special circuit module for breaking violence.

⑤ Sensorless switch designed, homing automatically when power-on. Door closing position can be set precisely.

24V DC 8A Incremental Encoder Servo Driver for Speed Gate and Turnstile Applications 5

24V DC 8A Incremental Encoder Servo Driver for Speed Gate and Turnstile Applications 6

Support Functions:

① Support RS232, RS485 and CAN, provide Modbus communication protocol；

② PC Monitor software with oscilloscope.

③ Firmware Download tools via Serial port;

④ Hand-held LED / LCD Tool box;

Specification:

Input Voltage	24 VDC / 48VDC
Rated/Peak Current	8 / 24 Arms
Overload	Load=200%(16Arms),overload time Maximum 10S
Brake Unit	Built-in brake resistance, rated 12W
Feedback	HALLU,HALLV,HALLW,EA,EB,EZ incremental encoder, +5V power supply Support differential input; Support 1000, 2400, 2500 resolution position feedback;
Brake Control	1 input NPN type brake control output, maximum 1.5A, 24VDC PWM output when 48VDC input
Hardware Protection	Power-input reverse connection, phase short circuit, 5V short circuit, brake output short circuit protection Low-voltage, Over-voltage, Over-current, Overheating
Level of Protection	IP20

Tag:
